AVMATRIX Shark S6 Plus Portable Video Switcher | 17.3" FHD 6-Channel SDI/HDMI Live Production Switcher | RTMP Streaming, Recording, PTZ Control, USB Capture, XLR Audio with Phantom Power

Product Description The AVMATRIX SHARK S6 PLUS is a professional all-in-one portable video switcher designed for multi-camera live production, streaming, and recording. Featuring a built-in 17.3-inch Full HD IPS screen and an integrated hardware control panel, it provides a complete mobile production solution without the need for additional monitors or control systems. With support for 6 SDI and 2 HDMI inputs, the SHARK S6 PLUS handles complex multi-camera setups for broadcast, live events, houses of worship, corporate presentations, and online streaming. The switcher includes powerful production tools such as chroma key, luma key, picture-in-picture, downstream key, logo overlay, and customizable transitions. Built-in RTMP streaming allows direct broadcasting to major platforms, while internal recording to USB or SD card ensures reliable content capture. Professional audio support includes balanced XLR inputs with phantom power, audio mixing, and delay adjustment. Integrated PTZ camera control and macro automation further streamline workflow and improve production efficiency. Technical Highlights Display 17.3" FHD IPS integrated monitor Inputs 6× 3G-SDI 2× HDMI (up to 4K) Outputs 2× HDMI PGM 4× SDI PGM 1× HDMI Multiview USB-C UVC capture Streaming & Recording RTMP streaming via LAN Record to USB or SD card (MP4/TS, up to 1080p60) Audio 2× XLR/TRS balanced inputs (48V phantom) 3.5mm line input/output 8-channel audio mixing Control & Workflow PTZ control (VISCA / ONVIF / Pelco) 20 macro presets Chroma key / Luma key / PIP×3 / DSK / Logo CUT / AUTO / T-bar transitions Power DC 15V (9–24V wide range) Warranty 2 Years SHARK S6 PLUS Users manual-2512… What’s in the Box SHARK S6 PLUS Switcher Power Adapter USB Cable Tally Connector User Manual

• AVMATRIX SHARK S6 PLUS Portable Video Switcher | 17.3" FHD 6-Channel SDI/HDMI Live Production Switcher | RTMP Streaming, Recording, PTZ Control, USB Capture, XLR Audio with Phantom Power
• All-in-One Portable Production Studio Built-in 17.3" Full HD IPS display with integrated control panel for switching, monitoring, streaming, and recording—ideal for mobile live production and field use.
• Flexible Multi-Camera Inputs (Up to 8 Sources) Supports 6× 3G-SDI and 2× 4K HDMI inputs, with 2× HDMI, 4× SDI program outputs, and dedicated HDMI multiview for professional multi-camera workflows.
• Built-in Live Streaming & Recording Stream directly via RTMP over LAN to YouTube, Facebook, or Twitch, and record internally to USB drive or SD card in MP4/TS format up to 1080p60.
• Professional Audio with 48V Phantom Power Includes dual XLR/TRS balanced inputs, 3.5mm line input, and full audio mixing of embedded and external sources—perfect for professional microphones and live events.
• Advanced Production Tools Features Chroma Key, Luma Key, PIP (×3), DSK, Logo overlay, transitions (CUT/AUTO/T-bar), and 20 programmable macros for efficient live operation.
• PTZ Camera Control & USB Capture Control up to 6 PTZ cameras via LAN or RS232/RS485 (VISCA/ONVIF/Pelco). USB-C output provides UVC capture for OBS, Zoom, Teams, vMix, and more.
